Simco-Ion Top Gun™ 3 Ionizing Air Gun
Simco-Ion Top Gun™ 3 Ionizing Air Gun
**Extended Lead-Times May Apply - Up to 7 Weeks**
The Simco-Ion Top Gun 3 is a high-performance ionizing air gun designed for a wide variety of electronic manufacturing, medical, and assembly applications. Balanced to 0±15V, the Top Gun 3 features high blow-off force and low air consumption for high-efficiency cleaning and maximum static charge decay. An integrated, replaceable filter-nozzle ensures that air contacting the target area is clean. The lightweight, ergonomic gun body features a light-touch trigger for comfort during extended use, with all functionality built in — including a flow control valve, balance adjustment for calibration, and a two-level LED indicating both power and ionization status. Both the gun body and cable are static dissipative.
Key Specifications
| Specification | Value |
|---|---|
| Part Number | 4005105-01 |
| Ion Balance | 0 ± 15V |
| Body & Cable | Static dissipative |
| Airflow Control | Integrated flow control valve |
| Filter | Integrated, replaceable filter-nozzle |
| Ionization Indicator | Two-level LED (power + ionization) |
| Mounting | Hanger included |
Key Features
- Balanced to 0 ± 15V — electrically balanced ion output for effective static neutralization
- High blow-off force, low air consumption — efficient cleaning with reduced compressed air costs
- Integrated replaceable filter-nozzle — ensures clean air at the target area
- Flow control valve — adjustable airflow to meet specific application requirements
- Two-level LED indicator — eliminates guesswork by confirming ionization at the target area
- Lightweight ergonomic design — light-touch trigger prevents operator fatigue during extended use
- Static dissipative gun and cable — safe for use in ESD-protected areas
- Balance adjustment — built-in calibration control for field adjustment
Optional Configurations
Top Gun 3 with Optical Sensor: For automated assembly, the Top Gun 3 is available with an optional Optical Sensor that automatically activates the gun when an object is detected in range. Adjustable range from 1–30 inches. Two LED indicators show sensor status and active ionization.
Top Gun 3 with Sidekick (Hands-Free): The Top Gun with Sidekick offers hands-free operation and flexible positioning during assembly and manufacturing. A foot pedal controls both ionization and airflow, reducing compressed air costs and extending ionizer life. Features an 18-inch fully adjustable neck and tabletop steel bracket for bench-top mounting.
Ideal Applications
- Electronics assembly and PCB handling in ESD-protected areas
- Medical device manufacturing and cleanroom assembly
- Static elimination during component placement and inspection
- Blow-off cleaning of ESD-sensitive assemblies and surfaces
- Automated assembly lines (with optional Optical Sensor)
Frequently Asked Questions
What does "balanced to 0 ± 15V" mean?
Ion balance refers to the ratio of positive to negative ions produced by the ionizer. A balance of 0 ± 15V means the Top Gun 3 produces nearly equal positive and negative ions, effectively neutralizing both positive and negative static charges without over-charging the target surface in either polarity.
Is the Top Gun 3 suitable for cleanroom use?
Yes — the integrated replaceable filter-nozzle ensures that air exiting the gun is clean before contacting the target area. The static dissipative body and cable are also appropriate for controlled environments.
Can the Top Gun 3 be used in automated assembly?
Yes — the optional Optical Sensor configuration automatically activates the gun when an object enters the detection range (1–30 inches adjustable), making it suitable for inline automated assembly processes.
