Rtv108-300Ml, Ge Rtv Silicone Adhesive Sealant

SKU: RTV108-300ML
Rtv108-300Ml, Ge Rtv Silicone Adhesive Sealant

Rtv108-300Ml, Ge Rtv Silicone Adhesive Sealant

SKU: RTV108-300ML
Regular price $24.08
/
Shipping calculated at checkout.
  • Secure Payments
Excellent for insulating, sealing, bonding and formed-in-place gaskets. Can be applied to vertical and overhead surfaces. Not for use in delicate electrical and electronic applications in which corrosion of copper, brass, or other sensitive metals is undesirable. Can be used in food contact applications where FDA regulations apply. Reference CDS4319 "Food Contact Applications", "Silicone Rubber Compounds." RTV108-300ML, GE RTV Silicone Adhesive Sealant
Primary Characteristics Clear Paste High Strength High performance assembly Acetoxy cure Meets MIL-A-46106 UL File no. E-36952 FDA 21 CFR 177.2600
Can be applied to vertical and overhead surfaces. Not for use in delicate electrical and electronic applications in which corrosion of copper, brass, or other sensitive metals is undesirable. Can be used in food contact applications where FDA regulations apply. Reference CDS4319 "Food Contact Applications", "Silicone Rubber Compounds."
Specifications Use Adhesive Sealant Special Feature High tensile strength Standards FDA 21CFR 177.2600 MIL-A-46106 UL Recognized UL File No. E-36952 UL 94 HB NSN 8030-01-014-5369 Cross Reference RTV 102, DC 732 GE Silicone NSN # 5962-01-050-0919 8040-00-701-9546 8040-00-843-0802 8040-01-010-8758 8040-01-173-9815 8040-01-041-1422 Uncured Properties Consistency Paste Color Translucent Specific Gravity 1.05 Tack Free Time 20 min Cure Through Time ( 77F / 50% relative humidity / 1/8" thick) 7 days Cure Time (@ 77F /50% relative humidity) 3 days Useful Temp. Range -60C to 205C (-75F to 400F) Cured Properties - MECHANICAL Hardness 30 (Shore A) Tensile Strength 28 kg/cm2 (400 psi) Elongation 450% Tear Strength 8 kg/cm (45 lb/in) Peel Strength 7 kg/cm (40 lb/in) Cured Properties - ELECTRICAL Volume Resistivity 3 x 1015 ohm cm Dielectric Strength 20 kV/mm (500 V/mil) Dielectric Constant 2.8 @ 60 Hz Cured Properties - THERMAL Thermal Conductivity 0.5 x 10-4 cal/sec/cm2 Brittle Point -60C (-75F) Thermal Expansion 7 x 10-5 (C)-1 Other Viscosity (@ 25C) 400 g/min
