JBC Tools PHN-SA, Nano PCB Support

This support is perfectly adapted to any type of small PCB up to 108 x 70 mm/4.25 x 2.71 in. by means of its many adjustable elements..

It allows fast, easy and precise PCB changing, guaranteeing a proper positioning, ideal for repetitive soldering jobs which means saving time and optimizing workflow.

When combined with PHN Nano preheater it can provide up to 3 clearance sizes from PCB to heater surface; its built in slots ensures a precise board-preheater alignment to always heat the same area.

1 PSN Nano PCB Support
ESD safe connector

DIMENSIONS AND WEIGHT

Net weight: 1,90 kg (4.19lb)
MAX. DIMENSIONS
Low position
238 x 237 x 75 mm
9.4 x 9.3 x 3 in
High position
238 x 237 x 96 mm
9.4 x 9.3 x 3.8 in
Max. PCB thickness
6 mm / 0.236 in
Package
280 x 280 x 164 mm / 2.4 kg

11.02 x 11.02 x 6.45 / 5.29 lb
