IDEAL-TEK ES5247.CR.BG.ITU Ergo-Tek Slim HP Cutters 5247, Small Oblique Narrow Full-Flush, OAL 130mm-5.12in

Ideal-Tek SKU: ES5247.CR.BG.ITU
Price
Regular price $93.32
Regular price Sale price $93.32
/
Minimum quantity allowed is .
Maximum quantity allowed is .
The product can be bought in quantity increments of .
Shipping calculated at checkout.

IDEAL-TEK ES5247.CR.BG.ITU Ergo-Tek Slim HP Cutters 5247, Small Oblique Narrow Full-Flush, OAL 130mm-5.12in

High Precision Cutters ES5247.CR.BG

High precision Ergo-tek Slim Cutters - Oblique head, full-flush. OAL: 130mm - 5.12". ESD safe

The 5247 is a high precision cutter belonging to the oblique head cutter family. The angled blade geometry supports the operator's ergonomics during the cut. The full-flush cutting edge is suitable to perform very clean cuts on small size material. The 5247 is equipped with an ESD Ergo-tek slim handle which allows an excellent grip, suitable to environments and to components susceptible to electrostatic discharge. The blades are hardened to 67HRC hardness.

TDS
Grip Handle TDS
Body Material TDS

Product Details
Category
High Precision Cutters
Reverse action
no
ESD safe
yes
Body material
100Cr6
Grip handle material
Ergo-tek Slim - TPE + PP
Body coating/ finishing
Sandblasted
Product width (mm - in)
60.00 - 2.362
Product height (mm - in)
18.00 - 0.709
Degree of bending
50.0
Head shape
Oblique
Head width (mm - in) - C
10.00 - 0.394
Size/type
Small
Cutting edges
Full-Flush
OAL (mm - in) - A
130.00 - 5.118
Head/Jaw length - B (mm - in)
18.00 - 0.709
Head thickness (mm - in) - D
6.40 - 0.252
Tip thickness - F (mm - in)
0.20 - 0.008
Blade length - G (mm - in)
8.00 - 0.315
Cutting capacity soft (mm)
0.10-1.20
Cutting capacity soft (AWG)
38-17
Cutting capacity medium (mm)
0.10-0.60
Cutting capacity medium (AWG)
38-23
Net weight (g-lb)
86.0 - 0.19
RoHS compliant
yes
