Hakko FX971-010 Soldering Station
Hakko
SKU: FX971-010
Hakko FX971-010 Soldering Station
Hakko
SKU: FX971-010
Regular price
$449.97
Sale price
$330.00
Minimum quantity allowed is .
Maximum quantity allowed is .
The product can be bought in quantity increments of .
FX-971 Soldering Station STATION,SDRG,ESD, W/O TIP, FX-971
The FX-971 is the latest bench top soldering station to come from Hakko.
A 100W station with a minimal footprint to maximize your workbench space, both a standard and micro handpiece, and an all-new holder for removing and storing tips. This new designed soldering station provides operators with a 15-degree face tilt, large LCD, multi-button functionality, and connects to the new Hakko Control Software. FX-971 is only compatible with the HAKKO CONTROL SOFTWARE V3 or higher.
Features & Benefits
For a dual-port soldering station please see the new FX-972 Dual-Port Soldering Station
Specifications
| Station | |
| Model Name | FX-971 |
| Part No. | FX971-010 |
| Power Consumption | 100W 120V |
| Temperature Range | 50° - 450°C (120° - 850°F) |
| Temperature Stability | ±3°C (±5°F) |
| Output Voltage | 24V |
| Outer Dimensions | 93(W) x 126(H) x 133(D) mm (3.7 x 5 x 4.8 in.) |
| Weight | 2.6 lb. (1.2 kg.) |
| Country of Origin | MYS |
| Soldering Iron - Handpiece | |
| Model Number | FX-9701 |
| Tip-to-Ground Resistance | < 2 OHMS |
| Tip-to-Ground Potential | < 2mV |
| Length of Cord | 3.9 ft. (1.2 m) |
| Total Length (w/o cord) | 188 mm (7.4 in.) |
| Weight (w/o cord) | 31g (0.067 lb./1.1 oz.) with T39-D24 tip |
What's in the box?
| Description | Part No. |
| Soldering Station | F-971 |
| Soldering Iron | FX-9701 |
| Power Cord | B2419 |
| Iron Holder | FH-215 |
| USB Cable | B5129 |
| Instruction Manual | -- |
| CD-ROM | -- |
Note: Tips are not included.
