Ge - Rtv102-85Ml, Silicone, One Part, White Paste

MG Chemicals SKU: RTV102-85ML
Ge - Rtv102-85Ml, Silicone, One Part, White Paste

Ge - Rtv102-85Ml, Silicone, One Part, White Paste

MG Chemicals SKU: RTV102-85ML
Regular price $13.93
/
Shipping calculated at checkout.
Excellent for insulating, sealing, bonding and formed-in-place gaskets. Can be applied to vertical and overhead surfaces. Not for use in delicate electrical and electronic applications in which corrosion of copper, brass, or other sensitive metals is undesirable. Can be used in food contact applications where FDA regulations apply. Reference CDS4319 "Food Contact Applications", "Silicone Rubber Compounds." RTV 102-85ML, Silicone, One Part, White Paste
Primary Characteristics White Paste High Strength High performance assembly Acetoxy cure Meets MIL-A-46106 UL File no. E-36952 FDA 21 CFR 177.2600
Specifications Use Adhesive Sealant Special Feature High tensile strength Standards FDA 21CFR 177.2600 MIL-A-46106 UL Recognized UL File No. E-36952 UL 94 HB Cross Reference RTV 102, DC 732 GE Silicone NSN # 8040-00-225-4548 8040-00-728-3088 8040-00-833-9563 8040-00-877-9872 8040-01-042-1421 9320-01-075-4814 8040-01-048-2399 8040-01-063-7509 8040-01-064-1946 Uncured Properties Consistency Paste Color White Specific Gravity 1.05 Tack Free Time 20 min Cure Through Time ( 77F / 50% relative humidity / 1/8" thick) 7 days Cure Time (@ 77F /50% relative humidity) 3 days Useful Temp. Range -60C to 205C (-75F to 400F) Cured Properties - MECHANICAL Hardness 30 (Shore A) Tensile Strength 2.8 kg/cm2 (400 psi) Elongation 450% Tear Strength 8 kg/cm 45 lb/in Peel Strength 7 kg/cm 40 lb/in Cured Properties - ELECTRICAL Volume Resistivity 3 x 1015 ohm cm Dielectric Strength 20 kV/mm 500 V/mil Dielectric Constant 2.8 @ 60 Hz Cured Properties - THERMAL Thermal Conductivity 0.5 x 10-4 cal/sec/cm2 Brittle Point -60C (-75F) Thermal Expansion 7 x 10-5 (C)-1 Other Viscosity (@ 25C) 400 g/min
