Lindstrom Ergo™ Micro-Bevel Precision Cut Diagonal Cutter with Oval Head 0.4-2 mm
Lindstrom RX-8160 — Ergo™ Micro-Bevel Precision Diagonal Cutter, Oval Head, 0.4–2mm
The Lindstrom RX-8160 is a professional-grade micro-bevel precision diagonal cutter designed for cutting leads, component legs, jewelry wire, and general electronics assembly applications. Features ESD-safe two-component Ergo™ handles, precision induction hardened cutting edges (63–65 HRC), and Lindstrom's Biospring® for reduced hand fatigue during repetitive cutting tasks.
Key Specifications
- Part Number: RX-8160
- Cutting Capacity: 0.4–2mm (solid copper wire)
- Head Style: Oval head
- Cutting Edge: Micro-bevel, induction hardened 63–65 HRC
- Handle: Two-component ESD safe Ergo™
- Material: High performance alloy steel
- Spring: Biospring® (3-position adjustable)
- Finish: Burnished
Applications
- Cutting component leads and wire in PCB assembly
- Jewelry wire cutting and precision craft applications
- General electronics assembly and rework
- ESD-sensitive assembly environments
- High-repetition cutting tasks requiring low hand fatigue
Frequently Asked Questions
What is the cutting capacity of the Lindstrom RX-8160?
The RX-8160 is rated for cutting solid copper wire from 0.4mm to 2mm diameter. Cutting capacity is specified for solid copper wire — stranded wire or harder materials may require a different cutter selection.
What does "micro-bevel" mean on the RX-8160?
Micro-bevel refers to the cutting edge geometry, which produces a very clean, precise cut with minimal deformation of the cut wire or lead. It is ideal for close-tolerance cuts in PCB assembly where lead length control is critical.
Is the Lindstrom RX-8160 ESD safe?
Yes. The two-component Ergo™ handles are ESD safe, making the RX-8160 suitable for use in ESD-controlled assembly environments.
What is the Biospring® on the RX-8160?
Biospring® is Lindstrom's ergonomic return spring system that reduces tension throughout the cutting cycle and can be adjusted to three different positions to match the operator's hand size and preference, reducing fatigue during repetitive cutting.
What is the difference between the RX-8160 and other Lindstrom RX series cutters?
The RX series offers multiple head styles, cutting capacities, and edge geometries. The RX-8160 features an oval head and micro-bevel edge optimized for precision lead cutting. Contact MTE Solutions for a comparison of Lindstrom RX series models for your specific application.
