Desco 12910 Static Shielding Bags, 3 inX5 in, 81705 Series, Metal-In, 100/Pk

Desco Static Shielding Bags | 100 pack of bags

Bag Dimension: 3" x 5"

Facts for Desco Part number 12910 static shielding bag:

Features:

• Lead-free RoHS compliant



• Listed on the qualified products list (QPL) Defense Standardization Program for electrostatic discharge (ESD) protective materials.


• Constructed and marked per requirements for heat-sealable bags used in military preservation.


• Material Identification Printed Between Polyester and Aluminum Shielding Layer


• Prevents markings from rubbing or sloughing off.


• Meets requirements1 for ESD shielding packaging inside and outside an ESD Protected Area (EPA).


• Allows bag to be used throughout an ESD Protected Area and grounded when placed on a grounded surface or handled by a grounded operator.


• Allows bag to be used with ESD susceptible items.

Specifications:

• Bag dimensions: 3" x 5"


• MIL-PRF-81705E Type III, Class 2 Qualified Film Laminate (0.0028”)


• Converted per MIL-DTL-117H


• Dissipative Outer Surfaces Rtt <1 x 1012 ohms per MIL-PRF-81705E Method 4.6.8


• Dissipative Inner Surface Rtt ≥ 1 x 105 to <1 x 1012 ohms per ANSI/ESD STM11.11


• <10 nJ Energy Limit Test per MIL-PRF-81705E Method 4.6.9

Meets the ANSI/ESD S20.20 and ANSI/ESD S541 requirements for ESD shielding packaging
