Aven Tools 10302 Technik Chain Nose Pliers, Smooth Jaws, ESD-Safe Grips, 5-Inch
Aven Tools 10302 Technik Chain Nose Pliers, Smooth Jaws, ESD-Safe Grips, 5-Inch
The Aven Tools 10302 Technik chain-nose pliers are designed for forming, bending and precision assembly work. Smooth jaws with a 1.80 mm tip width support controlled small-part handling, while the 127 mm overall length provides a compact bench-tool format. Mirror-finished 410 stainless steel, induction-hardened jaws and box-joint construction combine durability with consistent jaw alignment.
Position a component or lead between the smooth jaws, make a controlled bend, then let the dual leaf springs assist opening for the next operation. Cushioned grips, described by Aven as ESD-safe, add comfort during repetitive handling. Smooth contact avoids serration impressions, although excessive pressure can still mark delicate surfaces.
Best Uses / Applications
- Precision electronics assembly: Hold and position small components during detailed bench work.
- Lead forming and bending: Make controlled bends where the chain-nose profile suits the part and available access.
- Small-part repair: Grip suitable components with smooth contact surfaces rather than serrated jaws.
- Repeated assembly tasks: Use spring-assisted opening and cushioned grips during repetitive handling.
- ESD-controlled workstations: Use the manufacturer-described ESD-safe grips within an appropriately managed ESD process.
Key Features
- Chain-nose design with smooth jaws for forming, bending and component handling.
- 410 stainless steel with a mirror finish.
- Box joint supports durability and jaw alignment.
- Induction-hardened jaws for durability.
- Dual leaf springs assist repeated opening.
- Manufacturer-described ESD-safe cushioned grips.
- 26.6 mm jaw length and 1.80 mm tip width.
Technical Specifications
| Manufacturer / Series | Aven Tools / Technik |
|---|---|
| Part number / SKU | 10302 |
| Jaw style | Chain nose, smooth |
| Jaw length | 26.6 mm |
| Head width | 11.85 mm |
| Tip width | 1.80 mm |
| Overall length | 127 mm / 5 inches |
| Material | 410 stainless steel |
| Finish | Mirror finish |
| Joint | Box joint |
| Jaw treatment | Induction hardened |
| Opening assistance | Dual leaf springs |
| Grips | ESD-safe, cushioned, as described by Aven |
| Manufacturer-listed product weight | 0.25 lb |
The supplied material does not give grip resistance values or a specific ESD test standard. Confirm process-specific requirements before use. ESD-safe grips are not an electrical-insulation rating for energized work. No cutting capacity or wire-gauge capacity is specified.
Aven 10302 vs. 10303
| Specification | 10302 Chain Nose | 10303 Flat Nose |
|---|---|---|
| Jaw surface | Smooth | Smooth |
| Overall length | 127 mm | 114 mm |
| Jaw length | 26.6 mm | 23.6 mm |
| Tip width | 1.80 mm | 3.2 mm |
| Head width | 11.85 mm | 10.78 mm |
| Selection guidance | Chain-nose profile and narrower listed tip for precision forming and handling. | Flat-nose profile with wider listed tip for flat-contact bending and component handling. |
Frequently Asked Questions
What are the Aven 10302 pliers used for?
Aven describes them for forming, bending and precision assembly work, including suitable small-component handling.
Are the jaws serrated?
No. The manufacturer lists smooth chain-nose jaws. Smooth jaws avoid serration impressions but do not guarantee mark-free handling.
What is the tip width?
The specified tip width is 1.80 mm, with a 26.6 mm jaw length and 11.85 mm head width.
How do these differ from the Aven 10303?
The 10302 has a chain-nose profile, 127 mm overall length and 1.80 mm tip width. The 10303 has a flat-nose profile, 114 mm overall length and 3.2 mm tip width.
What stainless steel is used?
The supplied manufacturer specifications identify 410 stainless steel, refining the older listing's broader 400-series wording.
Are the grips ESD-safe?
Aven describes the cushioned grips as ESD-safe. The supplied material does not include resistance values or certification to a specific ESD standard.
What do the dual leaf springs do?
They assist opening between operations, supporting repetitive forming and handling tasks.
Can I cut wire or work on live circuits with these?
The supplied information establishes neither a cutting capacity nor an electrical-insulation rating. This model is described for forming, bending and precision assembly.
