MG Chemicals 838AR-P, Carbon Conductive Coating, 5ml Pen, Case of 5

MG Chemicals SKU: 838AR-P
MG Chemicals 838AR-P, Carbon Conductive Coating, 5ml Pen, Case of 5
MG Chemicals 838AR-P, Carbon Conductive Coating, 5ml Pen, Case of 5

MG Chemicals 838AR-P, Carbon Conductive Coating, 5ml Pen, Case of 5

MG Chemicals SKU: 838AR-P
Regular price $81.92
/
Minimum quantity allowed is .
Maximum quantity allowed is .
The product can be bought in quantity increments of .
Shipping calculated at checkout.

MG Chemicals 838AR-P, Carbon Conductive Coating, 5ml Pen, Case of 5

A circuit repair pen that dispenses acrylic lacquer pigmented with conductive carbon. The cured traces are durable and corrosion resistant, with fair conductivity. They adhere well to plastics and most electronics substrates. The valve tip opens when pressed against a surface, and the flow is controlled by squeezing the barrel. The product works best on a smooth, flat, hard surface, but the cured traces are highly flexible.

This circuit pen fixes damaged traces on keyboards, game controllers or remote controls. It is also useful for making small connections, such as jumpers and bridges. It is great for drawing resistors and can be used to increase the surface area of contacts by painting the area around them.

This pen is for low voltage or digital applications.

  • Creates durable, reliably conductive connections
  • Resistivity of 6.3 x 10-1Ω•cm
  • Typical trace width: 1.5 – 2 mm
  • Dries in 1 minute at room temperature
  • Superior corrosion resistance

Technical Data Sheet

Safety Data Sheet

Part # Net Vol. Net Wt. Packaging
838AR-P 5 mL 4.44 g Pen
